System Specifications
| Panel size/resolution | 10.1” / 1024 x 600 |
|---|---|
| System memory (standard/max) | 5,120 MB |
| System hard drive | 256 GB SSD (standard) |
| Interface | 10/100/1,000-Base-T Ethernet; USB 2.0; Wi-Fi 802.11 b/g/n (optional) |
| Network protocols | TCP/IP (IPv4/IPv6); SMB; LPD; IPP; SNMP; HTTP(S); AppleTalk; Bonjour |
| Automatic Document Feeder | Up to 80 originals; A5-A4; 50-128 g/m²; Dualscan ADF |
| Paper input capacity (standard/max) | 600 sheets / 1,600 sheets |
| Paper tray input (standard) | 1x 500 sheets; A6-A4; custom sizes; 60-210 g/m² |
| Paper tray input (optional) | 1x 500 sheets; A4; 60-90 g/m² 1x 500 sheets; A4; 60-90 g/m² |
| Manual bypass | 100 sheets; A6-A4; Custom sizes; 60-210 g/m² |
| Automatic duplexing | A4; 60-210 g/m² |
| Finishing modes | Group; Sort; Staple (offline) |
| Output capacity (standard) | Max. 250 sheets |
| Copy/print volume (monthly) | Rec. 6,500 pages; Max.¹ 120,000 pages ¹ If the maximum volume is reached within a period of one year, then a maintenance cycle must be performed |
| Toner lifetime | Black up to 13,000 pages CMY up to 9,000 pages |
| Imaging unit lifetime | Black up to 168,000 pages (imaging unit) CMY up to 55,000 pages (imaging unit) |
| Power consumption | 220-240 V / 50/60 Hz; Less than 1.45 kW |
| System dimension (WxDxH) | 420 x 528 x 572 mm (without options) |
| System weight | Approx. 39.0 kg (without options) |
Printer Specifications
| Print resolution | 1,800 (equivalent) x 600 dpi; 1200 x 1200 dpi |
|---|---|
| Page description language | PCL 6 (XL3.0); PCL 5c; PostScript 3 (CPSI 3016); XPS |
| Operating systems | Windows 7 (32/64); Windows 8/8.1 (32/64); Windows 10 (32/64); Windows Server 2008 (32/64); Windows Server 2008 R2; Windows Server 2012; Windows Server 2012 R2; Windows Server 2016; Windows Server 2019; Macintosh OS X 10.10 or later; Unix; Linux; Citrix |
| Printer fonts | 80 PCL Latin; 137 PostScript 3 Emulation Latin |
| Mobile printing | AirPrint (iOS); Mopria (Android); ineoPRINT (iOS/Android/Windows 10 Mobile); Mobile Authentication and Pairing (iOS/Android) Optional: Google Cloud Print; WiFi Direct |
Scanner Specifications
| Scan speed (mono/colour) | Up to 45/45 ipm in simplex Up to 90/90 ipm in duplex |
|---|---|
| Scan modes | Scan-to-eMail (Scan-to-Me); Scan-to-SMB (Scan-to-Home); Scan-to-FTP; Scan-to-Box; Scan-to-USB; Scan-to-WebDAV; Scan-to-URL; TWAIN scan |
| File formats | JPEG; TIFF; PDF; Compact PDF; Encrypted PDF; XPS; Compact XPS; PPTX Optional: Searchable PDF; PDF/A 1a and 1b; Searchable DOCX/PPTX/XLSX |
| Scan destinations | 2,100 (single + group); LDAP support |
Copier Specifications
| Imaging technology | Laser |
|---|---|
| Toner technology | HD polymerised toner |
| Copy/print speed A4 (mono/colour) | Up to 40/40 ppm |
| Autoduplex speed A4 (mono/colour) | Up to 40/40 ppm |
| 1st copy out time A4 (mono/colour) | 4.8/5.4 sec. |
| Warm-up time | Approx. 13 sec. in mono; 15 sec. in color² ² Warm-up time may vary depending on the operating environment and usage |
| Copy resolution | 600 x 600 dpi |
| Gradation | 256 gradations |
| Multicopy | 1-9,999 |
| Original format | A6-A4; Custom sizes |
| Magnification | 25-400% in 0.1% steps; Auto-zooming |
Fax Specifications
| Fax standard | Super G3 |
|---|---|
| Fax transmission | Analogue; i-Fax; Colour i-Fax; IP-Fax |
| Fax resolution | Up to 600 x 600 dpi |
| Fax compression | MH; MR; MMR; JBIG |
| Fax modem | Up to 33.6 Kbps |
| Fax destinations | 2,100 (single + group) |
User Box Specifications
| Storable documents | Up to 3,000 documents or 10,000 pages |
|---|---|
| Type of user boxes | Public; Personal (with password or authentication); Group (with authentication) |
| Type of system boxes | Secure print; Encrypted PDF print; Fax receipt; Fax polling |
System Features
| Security | Standard: ISO 15408 HCD-PP Common Criteria (in evalutation); IP filtering and port blocking; SSL2; SSL3 and TLS1.0/1.1/1.2 network communication; IPsec support; IEEE 802.1x support; User authentication; Authentication log; Secure print; Kerberos; Hard disk overwrite; Hard disk data encryption (AES 256); Confidential fax receipt; Print user data encryption Optional: Antivirus realtime scanning (Bitdefender®) |
|---|---|
| Accounting | Standard: Up to 1,000 user accounts; Active Directory support (user name + password + e-mail + smb folder); User function access definition Optional: Biometric authentication (finger vein scanner); ID card authentication (ID card reader); Authentication by mobile device (Android/iOS) |
| Software | store+find (opt.); convert+share (opt.); Device Manager; Box Operator; Data Administrator (user accounts |
- Toutes les caractéristiques se rapportent à du papier A4 de la qualité de 80 g.
- Le support et la disponibilité des caractéristiques et fonctionnalités énoncées dépendent des systèmes d'exploitation, des applications et des protocoles de réseau ainsi que des configurations réseau et système.
- L'espérance de vie des consommables est basée sur des conditions de fonctionnement spécifiques telles qu'une couverture pour une taille de page particulière (couverture de 5% de A4). La durée de vie réelle de chaque consommable varie en fonction de l'utilisation et d'autres variables d'impression, y compris la couverture de page taille, type de support, impression continue ou intermittente, température ambiante et de l'humidité.
- Certaines des illustrations produit contiennent des accessoires en option.
- Les caractéristiques et accessoires sont basés sur les informations disponibles au moment de l'impression et sont sujets à changement sans préavis.
- Develop ne garantit pas que toutes les spécifications mentionnées seront sans erreur.
- Tous les noms de marques et de produits peuvent être des marques déposées ou des marques commerciales de leurs détenteurs respectifs et sont reconnus par les présentes.
